JDPE-20EVS-PDF 20" EVS Drill Press with Power Downfeed 1-1/2HP, 115V, Single Phase
JDPE-20EVS-PDF 20" EVS Drill Press with Power Downfeed 1-1/2HP, 115V, Single Phase
Product SKU: JT9-354250
Couldn't load pickup availability
The 20'' JET JDPE-20EVS-PDF Drill Press produces high torque at all speeds in both forward and reverse necessary for a wide range of operations. Spindle is supported by high quality ball bearings reducing rotational friction while increasing load support. Engineered to maximize output, the 20’’ EVS Drill Press includes a three-speed power down feed for heavy drilling applications and capable of running various spindle speeds from 50 to 2000 RPMs. CSA/CUS Certified.
| Stock Number | 354250 |
|---|---|
| Base Dimensions (In.) | 17.7 x 25-1/2 |
| Base Work Table (In.) | 14-3/16 x 13 |
| Column Diameter (In.) | 4 |
| Distance Column to Spindle (In.) | 26-1/2 |
| Drilling Capacity Cast Iron (In.) | 1-1/4 |
| Drilling Capacity Mild Steel (In.) | 1-1/8 |
| Drills to Center of Circle (In.) | 10 |
| Gross Weight (Lbs) | 566 |
| Inverter Type / Power Source | 2HP/115V/1PH |
| Model Number | JDPE-20EVS-PDF |
| Motor Amps | 4.6 |
| Motor (HP) | 1.5HP, 230V, 3PH |
| Motor Power (HP) | 1.5 |
| Motor Voltage (V.) | 230 |
| Net Weight (Lbs.) | 477 |
| Overall Dimensions (L x W x H) (In.) | 32-3/5 x 22-2/3 x 70-25/64 |
| Prewired Voltage (V.) | 230 |
| Prop 65 | Cancer and Reproductive Harm |
| Quill Diameter (In.) | 2.16 |
| Range of Spindle Speeds (RPM) | Low: 50 - 390, High 270 - 2000 |
| Spindle Distance to Base (In.) | 48.85 |
| Spindle Distance to Table (Max.) (In.) | 32.6 |
| Spindle Taper (In. x TPI) | MT-3 |
| Spindle Travel Auto (In.) | 4-1/4 |
| Spindle Travel (In.) | 5" Manual | 4-1/4" Auto |
| Spindle Travel, Manual (In.) | 5 |
| Style (Type) | EVS |
| Table Size (L x W) (In.) | 16-1/2 x 18-1/2 |
| Tapping Capacity Mild Steel (In.) | 3/4 |
| Weight (Lbs.) | 477 |
Product Specifications
